BB-U2EIDE525D-1 IDE to USB2.0 5.25"
Dual Bay Enclosure
(TWO devices supports)




U2EIDE525D-1 is a USB 2.0 to IDE (ATA/ATAPI) external enclosure ideally suited for tailgating interface applications for removable-media drives - CD-ROM, CD-R, CD-RW, DVD-ROM, DVD-RAM, tape drive, and hard disk drive. U2EIDE525D-1 is designed to enable hot-swap/ plug-and-play operation for IDE (ATA/ATAPI) devices with the connection to USB 2.0 or USB 1.0 interface installed on a computer. U2EIDE525D-1 allows users to easily hot-swap IDE devices without interrupting the currently running operations. U2EIDE525-1 provides the perfect solution for data backup and transferring of data between computers using IDE (ATA/ATAPI) devices. It allows IDE drives (Master and Slave) to connect to the high-speed USB 2.0 serial bus in a plug-and-play fashion.



BB-U2EIDE525D-1 ATAPI to USB 2.0 5.25" Dual Bay Enclosure Feature:

USB Bus Transfer Rate: High Speed (480 Mbit) and Full Speed (12 Mbit)
bluebullet.gif (834 bytes) Fully Supports ATA33/66/100/133 TWO IDE Device Interface
bluebullet.gif (834 bytes) Hot-Plug, Plug & Play, *no need install drivers
bluebullet.gif (834 bytes) Fit 5.25" and 3.5" form factor TWO IDE devices,
Complies with T13's ATA/ATAPI-6 Draft Specification:
Fully Supports 48-bit addressing for large hard drives (>128GB) including USB2.0 interface
Seagate 160GB, IBM 180GB, Western Digital 250GB, Maxtor 300GB HDD Supported
Or Supports DVD-RAM, DVD-/+RW, CDRW-ROM, ZIP, JAZ, ORB 2.2GB, MO, etc drive.
bluebullet.gif (834 bytes) Save Money, Easy installation, No need setup ID or Terminators
480Mbit/sec Max. Data Transfers

With USB 2.0 Cable & Power cord


Hardware Requirements:

bluebullet.gif (834 bytes) Desktop PC: with either a built-in USB port or a USB to PCI Host Adapter
bluebullet.gif (834 bytes) Notebook PC: with either a built-in USB port or a USB to CardBus PC Card

OS Requirements:

bluebullet.gif (834 bytes) *Supports Windows 98SE/ME/2000/XP/2003 built-in SBP2 drivers
Mac OS 9.1,
Mac OS-X 10.x or later
(CDRW, DVD-/+RW in Windows 2000/XP Fully Support)
(CDRW, DVD-/+RW in Mac OS 9.1/9.2/9.21/9.22  with
Roxio Toast 5.02 Titanium Fully Support)
(CDRW, DVD-/+RW in Mac OS X 10.2 or 10.3 with
Roxio Toast 5.x Titanium For Mac OS X Fully Support)

Additional Links / Notes:

bluebullet.gif (834 bytes) Windows 2000 User: USB 2.0 Services Pack 4 (Recommend)
Download Windows 2000 SP4
Download Windows XP SP1
Roxio Toast 5.02 Titanium Burning Tools



Specifications are subject to change without notice.
All brands and product names are trademarks of their respective companies
All Products are made in Taiwan
