| Processor: |
 Intel
Socket 478
Design, Support Intel Pentium4 (400MHz FSB) CPU |
| Chipset: |
Intel FW82845 AGP 4x 400MHz North-Bridge &
Intel FW82801BA South-Bridge Chipsets |
| BIOS: |
4Mbits
Award BIOS 6.00: Support Plug & Play, PCI 2.2, CD-ROM, ATAPI, LS-120 and IDE
device Multi Boot Method |
| Processor Clock: |
Support
100,
103, 105, 109, 111, 114, 117, 120, 127, 130
Front Side Bus Selective by BIOS |
| Memory Size |
3 x 168pin DIMM SDRAM (Support
unbuffered 3.3V): Max. 3GB System Memory |
| Internal I/O Port: |
1 x Floppy Port, 1 x ECP/EPP LPT Port, 2 x (16C550
UART) COM Port |
| External I/O Port: |
1 x PS/2 Mouse Port, 1 x PS/2
Keyboard Port |
|
PCI IDE Interface: |
Max. 4 x IDE/ATAPI Device Interface, transfer data without any limitation |
| IDE Port : |
Supports Ultra DMA 33/66/100 Transfer Mode |
| Extension: |
1 x AGP
4x Port (1.5v, 4x Speed Sideband at 266MHz) |
|
5 x 32 bit PCI Bus Master
Standard Version 2.2 Interface |
|
1 x CNR Port |
|
4 x
USB Ports (Universal Serial Bus) (Connect Another 2 USB Devices : Cable Required) |
| Extension Kit: |
1 x IrDA Interface |
| Special Function: |
Built-in Realtek RTL8100 10/100Mbps LAN Controller (Can Disable) |
|
On-board ALC201A AC'97 Sound
(Can Disable) |
|
100/133MHz FSB Setup Jumper |
|
SB-Link
Connector (SB DOS Supports) |
|
PC Health
Monitoring: To check PC CPU temperature, system voltage and fan speed. When current
temperature over warning temperature system will have alarm to warning. |
|
Support
Win95/98/98SE/ME/2000/XP, Redhat Linux 7.x System Shutdown, Keyboard, Telephone/LAN Wake Up Function |
|
Fully Support Advanced Configuration and Power
Interface (ACPI) |
|
Support
Suspend
to RAM |
|
Certificates of ISO9001, Y2K Passed |
| Size: |
225mm x 305mm (L x W) |
|
Mainboard Format: |
Standard ATX Form Factor |
|
|
