| Processor: |
 |
Intel Slot-1+Socket370 2 in 1 Design, Support ALL
Intel Celeron/Pentium-II/III CPU (No need Slot-1's riser card) |
| Chipset: |
|
Intel i82443BX
North-Bridge
Intel i82371EB South-Bridge Newest Chipset |
| BIOS: |
|
2Mbits Award BIOS 4.51:
Support Plug & Play, PCI 2.2, CD-ROM, ATAPI, LS-120 and IDE device Multi Boot Method |
| Processor Clock: |
|
Support 66, 75, 83, 100, 103, 105, 110, 115 ,120, 124, 124A, 133, 133A, 140 & 150MHz FSB
(Max. 8x ratio), If running at 124A, 133AMHz, PCI Locked at 33MHz |
|
|
3 x 168pin DIMM SDRAM (Support unbuffered 3.3V): Max. 768MB Main Memory |
| Internal I/O Port: |
|
1 x Floppy Port, 1 x ECP/EPP LPT Port, 2 x (16C550
UART) COM Port |
|
|
1 x PS/2 Mouse Port, 1 x PS/2 Keyboard Port |
| PCI IDE Interface: |
|
Max. 4 x IDE/ATAPI Device Interface, transfer data
without any limitation |
|
|
Support PIO Mode 4, Compatible
with Ultra DMA 33/66 Mode |
| Extension: |
|
1 x AGP 2x 1.0 Port
(Sideband at 133MHz) |
|
|
4 x 32 bit PCI Bus Master Standard Version 2.1
Interface |
|
|
1 x 16 bit ISA Bus |
|
|
2 x USB Port (Universal Serial Bus) |
| Extension Kit: |
|
1 x IrDA Interface |
| Special Function: |
|
On board PCI ESS Solo-1 3D Sound
Controller, 100% DOS Games Support |
|
|
Support Win95/98/2000/Millennium/Redhat Linux 6.0
System Shutdown , Mouse, Keyboard, Telephone/LAN Wake Up Function |
|
|
Fully Support Advanced Configuration and Power
Interface(ACPI) |
|
|
Certificates of ISO9001, Y2K Passed |
| Size: |
|
180mm x 304mm (L x W) |
| Mainboard Format: |
|
Standard ATX Form Factor |
|
|
|
