| Processor: |
 |
Intel Socket370 Support ALL
Intel Cereon CPU up to 800MHz |
| Chipset: |
|
Intel i82810DC100 100MHz North-Bridge
Intel i82801AA South-Bridge & i 82802AB Chipsets |
| BIOS: |
|
Newest Award BIOS 6.0: Support Plug & Play, PCI 2.2, CD-ROM, ATAPI,
LS-120 and IDE device Multi Boot Method |
| Processor Clock: |
|
Support
66, 70, 75, 83, 90, 95, 100, 101, 105, 114, 133, 140, 150MHz
FSB
(Max. 8x ratio), If running at 133MHz FSB, PCI Locked at 33MHz |
|
|
2 x 168pin DIMM SDRAM
(Support unbuffered 3.3V): Max.512MB Memory |
| Internal I/O Port: |
|
1 x
Floppy Port, 1 x ECP/EPP LPT Port, 2 x (16C550 UART) COM Port |
|
|
1 x PS/2 Mouse Port, 1 x
PS/2 Keyboard Port |
| PCI IDE Interface: |
|
Max. 4 x
IDE/ATAPI Device Interface, transfer data without any limitation |
|
|
Support PIO Mode 4, Ultra DMA 33/66 |
| Extension: |
|
Integrated Direct AGP Intel752 2D/3D Display Chipset With 4MB Video Cache |
|
|
5 x 32 bit PCI Bus Master
Standard Version 2.2 Interface |
|
|
1 x AMR
Port (Audio Modem Riser) |
|
|
2 x USB Port (Universal
Serial Bus) |
| Extension Kit: |
|
1 x IrDA
Interface |
| Special Function: |
|
On
board PCI AC97 3D Sound Controller, You can manually disable it |
|
|
Suport
Win95/98/Redhat Linux 6.0 System Shutdown , Mouse, Keyboard, Telephone/LAN Wake Up Function |
|
|
Fully Support Advanced
Configuration and Power Interface(ACPI) |
|
|
Support
NEW Suspend To RAM (Power saving) |
| Size: |
|
190mm x 305mm (L x W) |
| Mainboard Format: |
|
Standard
ATX Form Factor |
|
|
|
