E-IDE / ATAPI interface |
|
|
7500 KB/sec max. data
transfer rate |
|
|
Supports Ultra DMA with 33.3MB/sec
burst data transfer rate |
|
|
130ms typical access time |
|
|
Compatible with CD-ROM, CD-Audio,
Video CD, CD-I / FMW, CD-R, CD-RW, CD Extra, I-Trax or I-Trax enhanced CD,Phone CD
multisession, Karaoke CD |
|
|
Anti-Vibration
System for consistent high speed reading |
|
|
Unique CD tray design 360° readable
|
|
|
Digital servo control |
|
|
MPC-3 Spec. compliant |
|
|
CD audio play / skip
button |
|
|
Digital volume control |
|
|
Emergency eject mechanism |
| Data
Transfer Rate |
|
|
Sustained 6000 KB/sec max |
|
|
Burst 33.3MB/sec (Ultra DMA mode) |
|
|
Access time : 130ms
typical |
|
|
Buffer Size 128KB
|
| Audio
Performance |
|
|
Signal to Noise Ratio 76dB min |
|
|
Distortion < 0.2% MAX @
1KHZ 4 |
|
|
Line output >1.7Vrms |
|
|
Sampling frequency
176.4KHz |
| Reliability
characteristics |
|
|
MTBF 30,000 POH (20% duty cycle at room temperature) |
| Audio
Output Ports |
|
|
Headphone
jack,Analog line-out connector, Digital line-out connector |
| Physical
Characteristics |
|
|
Front Panel: |
|
|
Headphone jack
|
|
|
Volume control buttons |
|
|
Power On/busy LED
indicator |
|
|
Emergency Eject pin hole |
|
|
Stop/Eject button |
|
|
Play/Skip button |
|
|
Rear Panel: |
|
|
Power supply connector |
|
|
IDE interface connector |
|
|
Master/Slave jumper |
|
|
Digital audio output connector |
|
|
Analog audio output
connector |
