VIA IEEE
1394 OHCI chipset on-board
(VIA Fire II VT6306 Single Chip) |
|
|
Compliant
IEEE 1394 and compatible with proposal 1394A |
|
|
Supports up
to 63 devices that can be run simultaneously on a system |
|
|
Support
1394 Transfer Rate for 100/200/400Mbits |
|
|
Descriptor
based isochronous and asynchronous DMA channels for receive and transmit packets |
|
|
PCI
2.1 interface |
|
|
3.3V power
supply with 5V tolerant inputs |
|
|
Three
cable ports |
|
|
Automatic
configuration to single-port, two-port and three-port applications |
|
|
Onboard
logic performs bus initialization and arbitration functions |
|
|
Incoming
data resynchronized to local clock |
|
|
Advanced
power management:
- Programmable power save mode on unconnected ports
- Sleep mode maximizes connected components power efficiency |
|
|
Easily
configured as a repeater |
|
|
Integrated
loop filter |
|
|
Single 3.3V
power supply |
|
|
32-bit PCI Bus Master design. Provides Three General Purpose I/Os |
|
|
Peer-to-Peer
Communication Structure |
|
|
Real-time
Transmission of Data Small, Durable, and Flexible Cable and Cable Connectors. |
|
|
Bus is
Dynamically Reconfigurable and Active. Termination is not Needed |
|
|
Lower
cost & Best performance for capturing digital video and audio from DV camcorders to
PCs |
|
|
Fully compatible
with Windows 98 SE / 2000 pre-installed standard device driver & Apple Mac OS 9.x with
FireWire 2.4, Linux 2.2.14 , Linux 2.2.16 supported |
|
|
最低系統配備: For DV Editing Requirement : Pentium II Class 333MHz
or higher, 64MB RAM. Windows 98 (Second Edition Recommend) or Windows 2000 Professional
Build 2195, Hard Disk at least keep 4MB/s transfer rate.
For MPEG2 Editing Requirement : Pentium II
350Mhz or Higher, 128MB RAM. AGP 2x Card Such as Riva TNT, Voodoo Banshee, Voodoo3, MPEG2
Decoder Compatible AGP Card. 6GB Space for editing
(Highly recommend Windows 98SE & Pentium III 450MHz for best
quality in MPEG-2 encoding) |
|
|
Operating environments:
Temperature from 0°C to 55 C°C
Relative humidity 95% maximum (Non-condensing) |
|
|
支援 JVC, Panasonic, Sharp, Canon, Sony DV/D8等手提攝錄機 |
|
|
附400Mbits 4p to
6p IEEE1394專用接線 |
|
|
附送最新Ulead Video Studio 4.0 SE Basic軟件,可同時攝取或制作全數碼DV影像,音效及制作VCD, MPEG1, ASF, RA壓縮等檔;
MP3音效輸入及BMP, JPG, TIF圖像輸出;
新增7國語言,包括英文,中文繁体版本;
亦可再透過專用接線,將制作好的DV資料回傳到DV攝錄機(PAL/NTSC) |
|
|
附送全港首套1394高速網絡專用軟件-FireNet:可同時支援TCP/IP, NetBEUI, IPX/SPX及 Appletalk通迅協定.直接安裝(1394接線),無須Hubs或Router.亦可同時支援PC Windows 98, Windows 98 Second Edition, Windows 2000 Professional,
Windows 2000 Advanced Server Edition及MAC OS 9.x 平台. |
|
|
File Format support
Input format
Video: DV, MPEG1, MPEG2, AVI, MOV
Image: BMP, JPG, EPS, FPX, MAC, PCD, PCT, PCX, PNG, TGA, TIF, WMF
Audio: AVI, MOV, MIDI, MPEG, WAV, MP3, Microphone, Music CD, Line in |
|
|
Output
format
Video: DV-AVI, MPEG1, MPEG2, AVI, ASF, BMP, JPG, TIF |
|
|
The BB-582VX
Package Contains :
- Bare-Bone's VIA Fire II IEEE-1394 Firewire Card (4 ports) x 1
- 4p to 6p i-Link 1394 cable x 1 (to connect the PC with your DV camcorder)
- Licensed Ulead Video Studio 4.0 SE Basic CD x 1
- Licensed FireNet 1.22 (PC/MAC) 1394 Networking Software CD x 1
- DV Upate driver CD x 1
- Bare-Bone's Warranty Card x 1
- English User's Manual x 1 |
|
|
If you create Video CD, you need to use Adaptec
Easy CD Creater 4.x Deluxe, NTI CD Maker
and Nero Burn 5.x VCD Format is 140KB/s Transfer Rate. |
