| Features |
 |
5-1/4 inch Half Height Form Factor |
|
Based on the Industrial Standard DVD Format
|
|
E-IDE / ATAPI interface |
|
Single and Dual Layer Disc can be replayed
(4.7GB /17GB) |
|
Backward read compatibility with existing
CD-ROM / CD-R / CD-RW discs |
|
Drive can be mounted either horizontal or
vertical orientations |
|
CD Multi-session disc compliant |
|
Multimedia MPC-3 Spec. compliant |
|
Windows PC97 Spec. Compliant |
|
|
| Specifications |
| Data Transfer Rate |
|
Sustained DVD-ROM:
8310KB/sec |
|
CD-ROM : 3600KB/sec (24x) |
|
| Data Capacity |
|
4.7GB (Single Layer) |
|
17GB (Dual Layer) |
|
| Buffer Size : 512KB |
| Audio Performance |
|
Number of Channels : 2 (Stereo) |
|
Frequency Response : 20Hz ¡V 20,000Hz +/- 3db |
|
Acoustic Noise : <45dB at 1m away from the
unit |
|
Distortion : < 0.1% max. (at 1KHz)
|
|
Line output : > 0.7Vrms typical |
|
| Reliability characteristics |
|
MTBF: 100,000 POH (20% duty cycle at room
temperature) |
|
Error Rate : Soft read error less than 10-9
|
|
Hard read error less than 10-12 |
|
Audio Output Ports Headphone
jack, |
|
Analog line-out connector, Digital line-out
connector |
| Power Requirements |
|
Voltage : |
|
DC +5V +/- 5% |
|
DC +12V +/- 10% |
| Environmental |
|
Temperature : |
|
Operating +5 ~ +45 degree C. |
|
Storage -30 ~+60 degree C. |
|
Humidity : |
|
Operating 15 ~ 85% |
|
Storage 10 ~ 90% |
|
|
| Dimension : 146x41.3x190mm (WxHxD) |
| Weight : 1.00KG |
| EMI Requirements : FCC-B, CE, C-Tick |
| Safety Requirements : UL, CSA, TÜV,
FDA, NORDIC |
